Secoroc Gold 64 DTH Hammer Drilling 114.3mm Extension Drill Rod

Name: Secoroc Gold 64 DTH Hammer Drilling 1143mm Extension Drill Rod
Brand: ROSCHEN
Price: 1 USD

Secoroc Gold 64 DTH Hammer Drilling 114.3mm Extension Drill Rod Manufactures

Brand Name : ROSCHEN

Model Number : Extension Drill Rod

Certification : ISO

Place of Origin : GERMANY

MOQ : Negotiable

Price : Negotiate

Supply Ability : 100000 pcs

Packaging Details : Steel Bundles

Name : Extension Drill Rod

Size : 114.3mm

Material : Carbon Steel

Application : DTH Hammer Drilling

Usage : Secoroc Gold 64

Item name : hard rock Mining Integral drill steel

Contact Now

Secoroc Gold 64 DTH Hammer Drilling 114.3mm Extension Drill Rod

Description:

Drill pipes that are used in applications such as DTH/ DTHR/ DR basically comprise of a steel pipe with a pin at one end and a box on the other. The job of the drill pipe is to transmit rotational torque and thrust from the drill rig rotary head to down hole drilling tools.
According to different application, different diameters of drill tubes are needed, basically, smaller DTH hammers need smaller DTH drill tubes, vice versa. Usually we are offering 50mm, 60mm, 76mm, 89mm, 95mm, 102mm, 114mm, 127mm, 140mm .

Parameters

Spanner Flat details can be agreed when ordering.
Outside Diameter (mm)	Bore	Thread (mm)	Thread	Wall Thickness (mm)	Popular Applications	mode	Standard Size
76.2	25.4	2.3/8″	API reg	4	DTH	Air Rotary
76.2	25.4	2.3/8″	API reg	6.35	DTH	Rotary
76.2	25.4	2.3/8″	API reg	8		Rotary
76.2	25.4	2.3/8″	API reg	9.5		Rotary
88.9	25.4	2.3/8″	API reg	4.5	DTH	Air Rotary
88.9	25.4	2.3/8″	API reg	6.35	DTH	Rotary
88.9	25.4	2.3/8″	API reg	8		Rotary
88.9	25.4	2.3/8″	API reg	9.5		Rotary
88.9	31.8	2.3/8″	API reg	6.35	DTH	Rotary	(HWY)
88.9	44.5	2.3/8″	IF	6.35	DTH	Rotary	(HWY)
88.9	44.5	2.3/8″	IF	8		Rotary	(HWY)
88.9	44.5	2.3/8″	IF	9.5		Rotary	(HWY)
101.6	25.4	2.3/8″	API reg	6.35	DTH	Rotary
101.6	44.5	2.3/8″	IF	8		Rotary	(HWY)
101.6	44.5	2.3/8″	IF	9.5		Rotary	(HWY)
114.3	38.1	3.1/2″	API reg	4.5	DTH	Air Rotary
114.3	38.1	3.1/2″	API reg	6.35	DTH	Air Rotary
114.3	38.1	3.1/2″	API reg	8	DTH	Rotary
114.3	38.1	3.1/2″	API reg	9.5		Rotary
114.3	44.5	2.7/8″	IF	6.35	DTH	Air Rotary
114.3	44.5	2.7/8″	IF	9.5		Rotary
127	68.3	3.1/2″	IF	6.35	DTH	Air Rotary
127	68.3	3.1/2″	IF	8	DTH	Rotary
127	68.3	3.1/2″	IF	9.5		Rotary
139.7	57.2	4.1/2″	API reg	8	DTH	Rotary
139.7	57.2	4.1/2″	API reg	9.5		Rotary
139.7	57.2	4.1/2″	API reg	12.5		Rotary
193.7	82.6	6.5/8″	API reg	12.5	DTH	Rotary
203.2	82.6	6.5/8″	API reg	9.5	DTH	Rotary
254	101.6	8.5/8″	API reg	16	DTH	Rotary

Pictures

Secoroc Gold 64 DTH Hammer Drilling 114.3mm Extension Drill Rod
